| 원래 장소: | 미국 |
| 브랜드 이름: | Bently Nevada |
| 인증: | CO.CQ |
| 모델 번호: | 330102-00-64-10-02-00 |
The Bently Nevada 330102-00-64-10-02-00 is part of the 3300 XL 8 mm Proximity Transducer System, specifically the Proximitor® Sensor.
This sensor is integral to the system, converting the eddy current signal from the proximity probe into a proportional
voltage output, facilitating precise shaft displacement and vibration
measurements in industrial machinery.
330102-00-64-10-02-00 Details
|
FAQ |
|
Q1: What does the part number 330102-00-64-10-02-00 signify? 330102: Model number for the 3300 XL 8 mm Probe. 00: Unthreaded length option ( 0.0 inches ). 64: Overall case length option (6.4 inches). 10: Total length option (10.0 meters). 02: Connector and cable-type option (Miniature coaxial ClickLoc connector, standard cable). 00: Agency approval option (Not required). Q2: Is the 3300 XL Proximitor® Sensor compatible with other Bently Nevada systems? Yes, components of the 3300 XL 8 mm system are backward compatible and interchangeable with other non-XL 3300 series 5 mm and 8 mm transducer system components. Q3: What are the power requirements for the Proximitor® Sensor? The Proximitor® Sensor requires a -17.5 Vdc to -26 Vdc power supply without barriers, consuming a maximum of 12 mA. Q4: What industries commonly use the 3300 XL Proximitor® Sensor? Industries such as power generation, oil and gas, aerospace, and process industries utilize this sensor for monitoring machinery health and performance. |
Inquiry now: miya@mvme.cn
3300 XL Proximity Probe
3300 Proximitor Sensor
3500 Power Supply
1900/65A
3500/42 Monitor Module
The 990 Vibration Transmitter
| 330130-040-02-CN | 330104-10-18-10-01-00 | 330104-03-06-05-02-00 |
| 330130-040-02-00 | 330104-08-16-10-02-00 | 330104-02-12-50-02-00 |
| 330130-040-01-CN | 330104-08-14-10-02-05 | 330104-02-10-10-02-00 |
| 330130-040-01-05 | 330104-06-14-50-02-00 | 330104-01-08-50-01-CN |
| 330130-040-01-00 | 330104-06-14-10-02-00 | 330104-01-06-10-02-00 |
| 330130-040-00-CN | 330104-06-12-10-02-00 | 330104-01-05-10-02-00 |
| 330104-13-20-10-02-00 | 330104-05-15-05-02-00 | 330104-00-25-10-02-05 |
| 330104-12-20-10-01-00 | 330104-05-10-10-02-05 | 330104-00-25-10-02-00 |
| 330104-10-20-10-02-05 | 330104-03-09-10-02-00 | 330104-00-24-50-02-00 |
| 330104-10-20-05-02-00 | 330104-03-06-10-02-00 | 330104-00-24-10-02-00 |
