330801-28-00-115-03-02 Bently Nevada PROXPAC XL Proximity Transducer Assembly For Measure Machinery Vibration And Position

Name: 330801-28-00-115-03-02 Bently Nevada PROXPAC XL Proximity Transducer Assembly For Measure Machinery Vibration And Position
Brand: MOORE AUTOMATION LIMITED
SKU: 330801-28-00-115-03-02
Availability: InStock

제품 상세정보:

원래 장소:	미국
브랜드 이름:	Bently Nevada
인증:	CO.CQ
모델 번호:	330801-28-00-115-03-02

상세 정보

원래 장소:

미국

브랜드 이름:

Bently Nevada

인증:

CO.CQ

모델 번호:

330801-28-00-115-03-02

330801:

PROXPAC XL 근접 변환기 어셈블리(영국식 슬리브 스레드 포함).

-28(조사 및 승인):

여러 국제 위험 지역 승인을 받아 구성된 3300 XL 8mm 프로브가 포함되어 있습니다.

-00(스탠드오프 어댑터):

스탠드오프 어댑터가 설치되어 있지 않습니다. 하우징은 기계 케이스에 직접적으로 위치합니다.

-115(프로브 관통):

가변 프로브 슬리브 깊이는 정확히 115mm로 설정됩니다.

-03 (피팅):

3/4-14 NPT 피팅 1개, 3/4-14 NPT ~ 1/2-14 NPT 스테인리스강 리듀서 1개 및 플러그 2개가 포함되어 있습니다.

-02(장착 나사):

스레드 크기는 표준 3/4-14 NPT 산업용 연결입니다.

강조하다:

High Light

강조하다:

Integrated Cableless Design

Built-in Proximitor

High-Precision Monitoring

거래 정보

최소 주문 수량:

가격:

inquiries

포장 세부 사항:

공장에서 봉인된 신규 및 원본

배달 시간:

2-3 근무일

지불 조건:

티/티

공급 능력:

요구합니다

제품 설명

330801-28-00-115-03-02 Bently Nevada PROXPAC XL Proximity Transducer Assembly

For measuring machinery vibration and position in industrial applications.

Product Overview

Unique Selling Point

Integrates the Proximitor sensor and 8mm probe directly inside a rugged PPS explosion-proof housing, completely eliminating external extension cables.

Customer Pain Points Solved

Addresses common field issues like cable damage, signal interference, and moisture ingress, while significantly reducing installation complexity.

Specific Applications

Ideally suited for critical rotating machinery vibration and position monitoring in harsh, hazardous oil, gas, or power plant environments (IP66/Type 4X).

Core Specifications

Linear Range: 2.0 mm (80 mils) - Covers a wide movement window to detect both tiny micro-vibrations and massive shaft shifts, preventing catastrophic machine crashes.
Target Calibration: AISI 4140 steel - Plug-and-play ready for most standard industrial shafts, completely eliminating the time and cost of field recalibration.
Protection Rating: IP66 & Type 4X - High-pressure waterproof and chemical-corrosion proof, ensuring years of maintenance-free operation in open-air rain or harsh oil refineries.

Technical Specifications

Probe Type	3300 XL 8mm eddy current probe
Linear Range	2.0 mm (80 mils)
Sensitivity	200 mV/mil (7.87 V/mm)
Target Material	AISI 4140 steel
Frequency Response	0 to 10 kHz
Power Supply	-17.5 Vdc to -26 Vdc
Protection Rating	IP66 and Type 4X
Housing Material	Glass-filled Polyphenylene Sulfide (PPS)
Operating Temperature	Housing: -52°C to +100°C; Probe: -52°C to +177°C
Mounting Thread	3/4-14 NPT
Penetration Depth	115 mm

Engineer's Note

"The PROXPAC XL series is a game-changer for field instrumentation. By eliminating the traditional extension cable and housing the Proximitor right at the probe sleeve, it completely removes the #1 failure point in proximity systems--cable damage from moisture and physical pinching. For this specific 330801-28-00-115-03-02 configuration, always verify that your machine casing clearance accommodates the 115 mm penetration depth to ensure the 8mm probe tip sits perfectly within its linear range relative to the shaft."

Frequently Asked Questions

Does the 330801-28-00-115-03-02 configuration require an external extension cable to connect to the rack?

No, it does not. The unique design of the Bently Nevada PROXPAC XL integrates the Proximitor sensor directly inside the protective housing cover. The internal 8mm probe connects straight to this sensor, meaning you only need standard field wiring from the housing terminal block to your 3500 monitoring rack, eliminating external extension cables entirely.

Can this specific transducer assembly be installed on a machine shaft made of a material other than AISI 4140 steel?

Yes, but it will require recalibration or scale factor verification. The assembly comes factory-calibrated for standard AISI 4140 steel to deliver its standard 200 mV/mil sensitivity. If your shaft uses a different alloy (such as K-Monel or Inconel), the output voltage will shift, requiring a custom calibration curve or a Bently Nevada magnetic properties cross-reference sheet.

What is the purpose of the '-00' option, and can I add a standoff adapter later if my insertion depth needs change?

The '-00' option means this unit features a "No Standoff Adapter" design, allowing the housing flange to mount flush against your machine casing. If your plant layout changes and you need to shorten the 115 mm penetration depth, you can order a separate Bently Nevada fluid-loc standoff adapter sleeve to pull the housing back without buying a completely new probe assembly.
